Crawler Type Mining Rope Saw Machine

The device is equipped with an efficient power system, which uses a high-power motor to release surging power, providing solid support for efficient cutting; At the same time, it innovatively adopts a track type design, which does not require additional tracks to be laid, and is flexible and easy to operate.

Email:alin@feilitool.com
mike@feilitool.com

The device is equipped with an efficient power system, which uses a high-power motor to release surging power, providing solid support for efficient cutting; At the same time, it innovatively adopts a track type design, which does not require additional tracks to be laid, and is flexible and easy to operate. It can greatly reduce the labor intensity of workers and adapt to complex terrain with ease. It can move freely in harsh environments such as mines, and is particularly adaptable to rough and uneven work sites. It is also equipped with multiple safety mechanisms such as overload protection and overheating protection to ensure operational safety. It is widely used in mining (such as marble, granite and other stone mining) and construction engineering (such as large concrete structure cutting and demolition) fields.

rated voltage AC380V±10%-50Hz
rated current 168A
Total power 95Kw
Host machine permanent magnet synchronous
Cable requirements 3 fire+1 ground 50 square soft copper wire
cutting efficiency 3-25m²/h
Wire speed of saw rope 0-36 m/s
Main wheel diameter 800mm
Auxiliary wheel diameter 380mm
movement speed 0-70m/h
rotation angle 360°
Maximum Traction 24000N
ambient temperature -10-40℃
Rope saw wheel rubber strip 42×8mm
Track model 280×72×58
Dimensions/mm 2300×1950×1500
host weight 3.2T
