Crawler Type Rope Saw Machine - Image 1
Click to enlarge
Rail Type Mining Rope Saw Machine
Rail Type Mining Rope Saw Machine
Back to products
Crawler Type Mining Rope Saw Machine
Crawler Type Mining Rope Saw Machine

Crawler Type Rope Saw Machine

This product boasts exceptional performance,equipped with a custom high-power motor that provides robust power and ensures efficient and stable operation.

Email:alin@feilitool.com
mike@feilitool.com

Get Quote

This product boasts exceptional performance,equipped with a custom high-power motor that provides robust power and ensures efficient and stable operation. Equipped with an automatic travel mechanism and a power-off function,it significantly enhances loading and unloading convenience and ease of operation,while also significantly enhancing operational intelligence and making work easier. Concerning durability,the product utilizes thickened steel plates and a plastic-spraying process, resulting in excellent corrosion resistance and a significantly extended service life. Furthermore,it is suitable for specialized environments such as outdoor bridge construction and demolition work, fully meeting the demands of such scenarios.

Crawler Electric Wire Saw Machine LL25

Dimensions (L*W*H) 1600×900×800mm Track Specifications 180×60×47mm
Net weight 600kg Maximum Traction Force 200kg
Travel Speed 0-18m/min Main Wheel Diameter 500mm
Cutting Line Speed 0-28m/s Drive Type Dual Frequency Conversion
Control Distance 50m Transmission Type Direct Drive
Operating Voltage 380v Control Type Remote Control
Main Motor Rated Current 50A Motion Type Crawler
Main Motor Power 25kW Minimum Ground Clearance 130mm
Total Power 28kW

Crawler Electric Wire Saw Machine LL55

Dimensions (L*W*H) 1600×900×800mm Track Specifications 180×60×47mm
Net weight 600kg Maximum Traction Force 200kg
Travel Speed 0-18m/min Main Wheel Diameter 550mm
Cutting Line Speed 0-31m/s Drive Type Dual Frequency Conversion
Control Distance 50m Transmission Type Direct Drive
Operating Voltage 380v Control Type Remote Control
Main Motor Rated Current 94.7A Motion Type Crawler
Main Motor Power permanent magnet55kW Minimum Ground Clearance 130mm
Total Power 58kW
